Hyundai Wia LV500RM/LM 15" Chuck Vertical Turning Centers with Live Tools
Have one to sell?
ConditionNew
New
The LV500 series vertical turning centers are designed by Hyundai WIA with years of expertise and using the very latest technology, maximizes productivity while maintaining rigidity and accuracy.
• Fanuc 32i-A Control
• 2,000 RPM spindle
• Powerful 40 Hp (30 kW) spindle motor
• Spindle orientation
• 87 PSI high pressure coolant system
• Double Pre-Tensioned Ball screws
• Fast 787 IPM (20m/min) X, and 709 IPM (18m/min) Z axis
• Auto Q-Setter
• Bed Flushing
• Two step (low & high) hydraulic chucking system
• BMT 75P 12 Station Turret [LV500RM]
• Rear Chip Conveyor (42” discharge height)
• 3 color tower signal light
• Rigid tapping
• 53 Gal (200 ℓ ) Coolant Tank
• Standard Hyd. Unit - 70Bar / 1,000psi / 13.2 Gal (50 ℓ) Tank
• Instruction manual, parts list, and electrical drawings
• Fanuc operator and maintenance manuals
• Two-year machine warranty: Parts: and 1 Year Labor
• Two-year control and motor warranty: Parts and Labor
