Hyundai Wia L400C BB 18" Chuck 2 Axis Big Bore Box Way Geared Spindle Turning Center

• Hyundai Wia Fanuc i control
• 1500 RPM spindle
• Gear box attached spindle motor + belt driven spindle
• 50HP(37kW) spindle motor
• Spindle orientation
• 87 PSI high pressure coolant system
• Double Pre-Tensioned Ball screws
• Fast 787 IPM (20m/min) X, and 984 IPM (25m/min) Z
• Auto Tool Setter
• 12 Station Turret
• Programmable built-in tail stock (Tow-along type)
• MT #4 Center
• Part Catcher Preparation
• Right Side Hinge Type Chip Conveyor (47” discharge height)
• 3 color tower signal light
• Manual Guide i
• Rigid tapping
• 79.3 Gal (300 ℓ) / [105.7 Gal(400 ℓ)] Coolant Tank
• Standard Hyd. Unit - 60Bar (870psi) / 5.3 Gal(20 ℓ) Tank
• Instruction manual, parts list, and electrical drawings
• Fanuc operator and maintenance manuals
• Two-year machine warranty: Parts; and 1 Year Labor
• Two-year control and motor warranty: Parts and Labor
