HYUNDAI WIA L300LMC 12" Chuck Box Way Live Tool Turning Center
Have one to sell?
ConditionNew
New
The Hyundai Wia L300 Series box way turning centers are designed by Hyundai WIA with years of expertise and using the very latest technology, maximizes productivity while maintaining rigidity and accuracy.
• Hyundai Wia Fanuc i control
• 3,000 RPM spindle [Big Bore: 2,800 rpm]
• Powerful 30HP (22kW) spindle motor
• Belt driven Spindle
• Spindle orientation
• 87 PSI high pressure coolant system
• Double Pre-Tensioned Ball screws
• Fast 787 IPM (20m/min) X, and 945 IPM (24m/min) Z
• Manual Tool Setter
• 12 Station Turret
• Programmable tail stock (Tow-along type)
• MT #5 Live Center
• Part Catcher Preparation
• Right Side Hinge Type Chip Conveyor (47” discharge height)
• 3 color tower signal light
• LNS bar feeder interface
• Rigid tapping
• 71.3 Gal(270 ℓ) Coolant Tank
• Standard Hyd. Unit - 35 Bar (508 psi) / 5.3 Gal(20 ℓ) Tank
• Instruction manual, parts list, and electrical drawings
• Fanuc operator and maintenance manuals
• Two-year machine warranty: Parts; and 1 Year Labor
• Two-year control and motor warranty: Parts and Labor
