HYUNDAI WIA HD2200 8" Chuck 2 Axis Box Way Turning Center

CAPACITY:
Swing over bed Ø21.7” (Ø 550mm)
Swing over carriage Ø15.4” (Ø 390mm)
Maximum turning diameter Ø15” (Ø 380mm)
Maximum turning length 22.2” (565mm) / [21.7” (550mm) on HD2200C]
Bar Capacity Ø2.6” (Ø 65mm) / [Ø3.2” (Ø 81mm) on HD2200C]

SPINDLE:
Chuck size 8” / [10”]
Spindle bore Ø3” (Ø 76mm) / [Ø3.62” (Ø 92mm)]
Spindle speed 4,000 rpm / [3,500 rpm]
Spindle nose A2-6 / [A2-8]
A.C. Spindle Motor (30 min. rating) 25 HP (18.5 kW)
Maximum spindle torque (30 min. rating) 260.5lbf-ft (353 N-m) [300lbf-ft (403 N-m) on HD2200C]

TRAVEL:
X axis travel 8.5” (215mm)
Z axis travel 22.8” (580mm)
X / Z axis rapid traverse rate 945 IPM (24m/min)/ 1,181 IPM (30m/min)
X / Z axis ball screw diameter Ø 1.26”/1.57” (Ø 32mm/ Ø 40mm)
X axis guideway span 10” (255mm)
Z axis guideway span 11.7" (297mm)

TURRET:
Number of tools 12
Turning tool shank size 1” (25mm)
Boring bar diameter Ø 1.6” (Ø 40mm)
Turret index time (1 step) 0.12 sec
Turret clamping force 9,608 lbs.

PROGRAMMABLE TAIL STOCK (Tow-along type):
Tailstock quill diameter Ø 2.56” (Ø 65mm)
Tailstock quill stroke 3.15” (80mm)
Tailstock body stroke 20.2” (514mm)
Tailstock spindle taper MT #4
Maximum tailstock quill thrust 992 lbs.

COOLANT and HYDRAULIC SYSTEM:
Coolant tank capacity 40 gal (150 liter)
Hydraulic tank capacity and required oil 4 gal (15 liter) / VG32 or CB32
Lubrication tank capacity and required oil 0.5 gal (1.8 liter) / G68

GENERAL:
Machine Height 72” (1,820 mm)
Floor Space (L) with chip conveyor 155.8” (3,962mm) / [160” (4062mm)]
Floor Space (W) 65” (1,650 mm)
Machine weight 9,039 lbs. (4,100kg) / [9,259 lbs. (4,200 kg)]
Power required 23 kVA / 60 amp @ 220V
Voltage required 205 - 235 Volts / 3 Phase

Specifications are subject to change for improvement without notice.
