Hyundai Wia SE2200LMC 10" Chuck Live Tool Turning Center
Have one to sell?
ConditionNew
New
The SE2200LMC compact live tool turning center is designed by Hyundai WIA with years of expertise and using the very latest technology, maximizes productivity while maintaining rigidity and accuracy.
• Hyundai Wia Fanuc i series - Smart Plus controller
• Max. 3,500 RPM Belt driven spindle
• Powerful 20.1HP (15 kW) spindle motor
• Spindle orientation
• 87 PSI high pressure coolant system
• Double Pre-Tensioned Ball screws
• Fast 1,181 IPM (30m/min) X and 1,417 IPM (36m/min) Z axis rapid traverse
• Manual Tool Setter
• Parts Catcher
• Right Side Hinge Type Chip Conveyor (37” discharge height)
• 3 color tower signal light
• LNS bar feeder interface
• Rigid Tapping
• 52.8 gal (200 ℓ) Coolant Tank
• Standard Hyd. Unit - 35 Bar (508 psi) / 4 gal (15 ℓ) Tank
• Instruction manual, parts list, and electrical drawings
• Fanuc operator and maintenance manuals
• Two-year machine warranty: Parts / 1 Year Labor
• Two-year control and motor warranty: Parts and Labor
