Hyundai-Wia KH63G 630mm Heavy Duty Dual Pallet Box Way Geared Head Horizontal Machining Center
Have one to sell?
ConditionNew
New
The KH63G is manufactured using the latest state-of the-art manufacturing technology and is one of the most versatile members of HYUNDAI-WIA’s outstanding line of CNC Horizontal Machining Centers. The KH63G has been designed to meet the demanding requirements found in today metal working market.
• Fanuc 31i-BControl
• 8,000 RPM spindle
• Powerful 26kW (35 HP) spindle with 2 speed geared head
• High precision spindle with double row angular contact ball bearings
• CAT # 50 Spindle Taper
• 1 degree index table (Opt 0.001 Degree)
• Oil jacket spindle cooler
• 1,000 PSI through the spindle coolant.
• Massive Meehanite cast iron bed
• Wide induction hardened and precision ground guide ways
• Low friction fluoroplastic resin mating way surfaces
• Double Pre-Tensioned Ball screws
• Fast 20m/min (787 IPM) X,Y and Z rapid traverse
• Rigid tapping
• Custom Macro (User Definable)
• Cam Type Double Arm ATC 90 Tools
• Automatic pallet changer with (2) Tapped pallets
• Qualified edge locators
• Pallet rotation at pallet loading station
• Portable Manual Pulse Generator
• Program and data protection key switch
• Metered piston distributor lubrication
• Telescopic way covers
• Full enclosure splash guard
• (2) screw type conveyors in the machine
• Chip Conveyor (32” discharge height)
• Flood coolant with large separate coolant tank
• Work light
• 3 color tower signal light
• Instruction manual, parts list, and electrical drawings
• Fanuc operator and maintenance manuals
• Two-year machine warranty: Parts and 1 Year Labor
• Two-year control and motor warranty: Parts and Labor
