HYUNDAI-WIA F500D with APC (Automatic Pallet Changer)
Have one to sell?
ConditionNew
New
F500D has been designed for high productivity, high speed machining, and precision accuracy. The travel column design with an integral 180 degree turning table allows the operator to load/unload the part while machine is running with the pallet. The large span of the column increases the machine rigidity for heavy cutting. 30 position tool magazine provides the tool storage required for multiple part run.
• Hyundai Wia Fanuc i Control / HYUNDAI -iTROL
• 10,000 RPM spindle
• Powerful 15kW (20 HP) belt driven spindle
• High precision spindle with double row angular contact ball bearings
• CAT #40 Spindle Taper
• Central hydraulic supply system : 2 x 3 ports (2 hydraulic ports and 1 air port)
• Spindle orientation
• Spindle override
• 290 PSI through the spindle coolant.
• Massive Meehanite cast iron bed
• Double Pre-Tensioned Ball screws
• Fast 40m/min (1,653 IPM) X,Y and 30m/min (1,181 IPM) Z axis
• Rigid tapping
• Custom Macro (User Definable)
• Twin Arm 30 Tool magazine
• Portable Manual Pulse Generator
• Program and data protection key switch
• Telescopic way covers
• Large separate coolant tank
• Work light
• 3 color tower signal light
• Instruction manual, parts list, and electrical drawings
• Fanuc operator and maintenance manuals
• Two-year machine warranty: Parts; and 1 Year Labor
• Two-year control and motor warranty: Parts and Labor
