HYUNDAI WIA HD2200C 10" Chuck 2 Axis Box Way Turning Center

• Hyundai Wia Fanuc i control
• 3,500 RPM spindle
• Powerful 25HP (18.5kW) spindle motor
• Spindle orientation
• 87 PSI high pressure coolant system
• Double Pre-Tensioned Ball screws
• Fast 945 IPM (24m/min) X, and 1,181 IPM (30m/min) Z axis
• Manual Tool Setter
• Programmable tail stock (Tow-along type)
• MT #4 Live Center
• Parts Catcher
• Right Side Hinge Type Chip Conveyor (42” discharge height)
• 3 color tower signal light
• LNS bar feeder interface
• Rigid tapping
• 39.6 Gal (150 ℓ) Coolant Tank
• Standard Hyd. Unit - 35 Bar (508 psi) / 4 Gal(15 ℓ) Tank
• Instruction manual, parts list, and electrical drawings
• Fanuc operator and maintenance manuals
• Two-year machine warranty: Parts: and 1 year Labor
• Two-year control and motor warranty: Parts and Labor
